Clear Fused Silica Windows Quartz Glass Sheet Fused Disc Optical Quartz Glass Slab Panels

FOB Reference Price:Get Latest Price
$1.00 - $100.00 / Pieces | 1 Piece/Pieces Clear Fused Silica Windows Optical Quartz Glass Slab (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
China (Mainland), Liaoning, China (Mainland)
Brand Name:
SUCCESS
Model Number:
Success-092901
Product name:
Clear Fused Silica Windows Panels
Type:
Plate/Sheet/windows/wafer
Surface:
Polishing
Model No.:
Success-092901
Shape:
Round /Square etc
MOQ:
1 Piece
Brand:
SUCCESS
Standard:
ISO9001 and CE
Package:
Standard
Supply Ability
Supply Ability:
10000 Piece/Pieces per Week Clear Fused Silica Windows Optical Quartz Glass Slab
Packaging & Delivery
Packaging Details
Professional and Safe package, inner by carton box, outer by wooden case.
Port
Dalian
Lead Time :
According to customer's demand

Clear Fused Silica Windows Quartz Plate Quartz Glass Sheet Fused Quartz Disc Fused Wafer Optical Quartz Glass Slab Panels

Product Description



 1.The Quartz glass plate/sheet can be customized according to customer's request.



   Size&design:Clear Fused Silica Windows

        we can accept customize according to different diameter ,thickness,length or sending your drawing.



  2.Advantage of Quartz Glass Plate/Sheet:

1)High purity :SiO2> 99.99%.
2)Operating Temperature: 1250℃; SoftenTemperature: 1730℃ .
3)Excellent visual and chemical performance:acid-resistance,alkali resistance,Good thermal stability
4)Health care and environmental protection.
5)No air bubble and no air line.
6)Excellent electrical insulator.



WE CAN DO:

1. Different raw materials for different application for customer choose.

    JGS1 (Far Ultraviolet Optic Quartz sheet)

     JGS1 (Far Ultraviolet Optic Quartz slab)

    JGS2 (Ultraviolet Optic Quartz slab)
    JGS 3 (Infrared Optic Quartz slab)
2. Strict size and tolerance control.
3. Professional inspection before deliver.



∗ Physical Property:



Character

Value

Density

2.2×103kg/m2

Hardness

570KHN100

Tensile strength

4.8×107Pa(N/m2)

Compression strength

>1.1×109 Pa

Coefficient of thermal

expansion (20℃-300℃)

5.5×10-7cm/cm℃

Thermal conductivity (20℃)

1.4W/m℃

Specific heat(20℃)

660J/kg℃

Softening point

1730℃

Annealing point

1250℃



Application:

Semiconductor ,Electric light,Laser,Lenses,Military,Metallurgical,optical instrument,high temperature window.



Picture Display







Quality Control


 Clear Fused Silica Windows

Packaging & Shipping

 Clear Fused Silica Windows



Company Information



Jinzhou City Success Quartz Glass Factory was founded in 2004 year, the factory has so many senior engineer who worked in former Jinzhou city 155 factory which a famous quartz glass manufacturer in China before.



The company developed quickly these years, we have several production lines and strong technical forces, we will study and improve our process continually, we produce various kinds quartz glass products with the exquisite technology and best raw material for customer. The quartz glass products widely used in electric light source, optical fiber field, semi-conductor, laser, optical instrument, laboratory instrument, medical treatment, chemical industry, melting metal, national defense and so on.



We produce and export variety of transparent and quartz glass products, mainly including quartz glass tube, quartz glass plate,quartz glass crucible, quartz glass instrument, quartz heating lamp,UV germicidal lamp, quartz rod, different Infrared and Ultraviolet quartz glass and other relation quartz glass products. Especially we have a great achievement on Quartz singing products, we have our own brand CVNC®, Quartz singing products including Quartz crystal singing bowl, Quartz crystal singing forks,Quartz crystal singing pyramid, singing harp and so on.



Our business philosophy is survive on quality, reputation for development. The products widely sales to all of the world, such as America, Germany, France, Italy, Australia, Canada, Britain, Spain, Sweden, Mexico, Argentina, Chile, Russia,India, Japan and other too many countries.

We will provide best quality, best service and best price, warmly welcome your visit !
